PRODUCT DESCRIPTION

 Machine Specification:

Screw diameter	mm	50	55	60
Screw L/D ratio	L/D	23.1	21	19.3
Shot weight	gram	447	540	643
Injection capacity	cm3	491	594	707
Injection pressure	Mpa	215	178	149
Theoretical injection rate	g/s	145	175	208
Plastic capacity	g/s	22.4	28.7	35.4
Injection stroke	mm	250
Screw torque	N.m	1510
Max screw rotate speed	r/min	170
Clamping force	ton	200
Opening stroke	mm	500
Space between tie bars	mm	505×505
Mould height	mm	190~530
Max daylight	mm	1030
Ejector force	ton	5.31
Ejector stroke	mm	125
Ejector quantity		5
Oil pump motor	kw	18.5
Pump pressure	Mpa	16
Heating power	kw	16.6
Machine size	M	5.9*1.5*2.0
Machine weight	ton	6.8
Oil tank capacity	L	420
International designation		2000-1060



Machine Features:
