PRODUCT DESCRIPTION

Machine Specification:

Screw diameter	mm	65	70	75
Screw L/D ratio	L/D	22.6	21	19.6
Shot weight	gram	966	1120	1286
Injection capacity	cm3	1061	1231	1413
Injection pressure	Mpa	203	175	152
Theoretical injection rate	g/s	308	357	410
Plastic capacity	g/s	50.6	60.5	71.5
Injection stroke	mm	320
Screw torque	N.m	2860
Max screw rotate speed	r/min	150
Clamping force	ton	380
Opening stroke	mm	680
Space between tie bars	mm	680×680
Mould height	mm	250~710
Max daylight	mm	1390
Ejector force	ton	9.07
Ejector stroke	mm	170
Ejector quantity		13
Oil pump motor	kw	37
Pump pressure	Mpa	16
Heating power	kw	25
Machine size	M	6.8*2.0*23
Machine weight	ton	15
Oil tank capacity	L	820
International designation		3800-2150

Machine Features:
