PRODUCT DESCRIPTION

Machine Specification:

Screw diameter	mm	70	75	80
Screw L/D ratio	L/D	22.6	21	19.7
Shot weight	gram	1225	1406	1600
Injection capacity	cm3	1346	1545	1758
Injection pressure	Mpa	201	175	154
Theoretical injection rate	g/s	370	423	484
Plastic capacity	g/s	60.4	71.4	83.7
Injection stroke	mm	350
Screw torque	N.m	3490
Max screw rotate speed	r/min	150
Clamping force	ton	480
Opening stroke	mm	770
Space between tie bars	mm	760×760
Mould height	mm	280~790
Max daylight	mm	1560
Ejector force	ton	11.34
Ejector stroke	mm	195
Ejector quantity		13
Oil pump motor	kw	45
Pump pressure	Mpa	16
Heating power	kw	28
Machine size	M	7.5*2.1*2.45
Machine weight	ton	20
Oil tank capacity	L	850
International designation		4800-2710

Machine Features:
