PRODUCT DESCRIPTION

Machine Specification:

Screw diameter	mm	100	110	120	130
Screw L/D ratio	L/D	24.5	22	20.2	18.6
Shot weight	gram	3715	4496	5350	62
Injection capacity	cm3	4083	4941	5880	6901
Injection pressure	Mpa	206	171	143	122
Theoretical injection rate	g/s	695	841	1001	1175
Plastic capacity	g/s	96	116	130	148
Injection stroke	mm	520
Screw torque	N.m	8690
Max screw rotate speed	r/min	110
Clamping force	ton	1000
Opening stroke	mm	1160
Space between tie bars	mm	1110×1110
Mould height	mm	450-1200
Max daylight	mm	2360
Ejector force	ton	24.5
Ejector stroke	mm	350
Ejector quantity		21
Oil pump motor	kw	90
Pump pressure	Mpa	16
Heating power	kw	68.45
Machine size	M	12.38×2.8×3.5
Machine weight	ton	60
Oil tank capacity	L	1700
International designation		10000-8410

Machine Features:
